700bar/10000psi Electric Hydraulic Tensioner Pump
-
Reservoir Capacity: 4L
Flow at Rate Pressure: 0.4 L/min
Motor Size: 1.5KW
Maximun Operating Pressure: 700bar 10000psi
Input Power:110V-240V/50HZ/60HZ
Weight: 17 KG
Minimum Order:1Piece
Manufacturer:SAIVS
Country of Origin:China
Application:UtilitiesDemolition & recyclingPharmaceuticalsMaterial handling
Sample:Contact us for free samples
Price:$1,530.00
Two speed operation reduces cycle time for higher productivity and efficiency.
Double overloading protection, built-in safety valve to prevent overloading, externally adjustable relief valve allows control of operating pressure.
Different control valves fit special working requirement.
Durable aluminum oil tank for excellent heat dissipation, rustproof, easy handling and also with a liquid leveling meter for rapid and convenient monitoring.
Equipped with manual switch to be more safe and reliable.
Light weight and portable design provides a high power-to-weight ratio.
Valve Select:
HM43: 4/3 valve, for double acting cylinder
HM32: 3/2 vale, for single acting cylinder
HM33: 3/3 vale, for single acting cylinder
Applications: Suitable for nut splitters, flange spreaders, single and double acting small Hydraulic Cylinders and other hydraulic tools.
PROVIDING EXCELLENT SOLUTIONS BY SAIVS™
if you are looking for factory manufacturers and suppliers of 700bar/10000psi Electric Hydraulic Tensioner Pump,
choose SAIVS TOOL because of the high quality, variety of choices, low price and fast delivery.
you can easily find the best 700bar/10000psi Electric Hydraulic Tensioner Pump solution here!
Speak to one of our experts today to learn more about our 700bar/10000psi Electric Hydraulic Tensioner Pump products solutions.
| Model Number | Oil Flow (L/min) | Pressure (bar) | Power | Usable Oil Capacity | Air Pressure Range | Weight | Dimensions | ||
| High Pressure | Low Pressure | High Pressure | Low Pressure | kw | L | bar | kg | L x W x H(mm) | |
| PA4 | 0.4 | 4 | 700 | 40 | 1.5 | 4 | 3-8 | 17 | 342*210*395 |
Can you customize my products?
Yes, we can customized products with your design drawings like DWG, DXF, DXW, IGES, STEP, PDF etc.
What is the MOQ?
It depends on what you are buying. Normally, our minimum order is one 20' full container
and LCL container (less than a container load) can be acceptable.
Where are your products manufactured?
Our factory is located in Ningbo, Zhejiang, China.
Do you provide OEM service?
Yes, we provide OEM service. We will produce products that meet your requirements according to the logo,
product parameters and dimensions you provide. Please contact us for more details.
