Electric Hydraulic Pump Station PE1/PE2/PE2D
-
Model:PE1/PE2/PE2D
Oil capacity:5L/2.4L/5L
Flow:0.7L/min(high pressure),6L/min(low pressure)
Voltage:AC220V/340W/750W
Pressure:700bar/10000PSI
Weight:25kg/16kg/25L
Length of oil hose:2M
Application:Furniture manufacturing and assemblyMining and resource developmentOil and gas industry
Sample:Contact us for free samples
Description
Model:PE1 Technical specification:
Oil capacity:5L
Flow:0.7L/min(high pressure),6L/min(low pressure)
Voltage:AC220V/750W
Pressure:700bar
Weight:25kg
Length of oil hose:2M
Characteristic:
1.The 2m wired remote controller to control the actions of oil delivery and return
2.Solenoid valve controlled hydraulic pump
3.The output can control inching motion, and can control oil output, stop, return and other actions at any time, so as to have the correct operation position in the work
4.Have pressure maintaining function
2.Model:PE2 Technical specification:
Oil capacity:2.4L
Flow:0.32L/min(high pressure),2.6L/min(low pressure)
Voltage:AC220V/340W
Pressure:700bar
Weight:16kg
Length of oil hose:2M
Characteristic:
1.Wired remote controller to control the actions of oil delivery and oil return.
2.Solenoid valve controlled hydraulic pump.
3.The inching motion can be controlled and the oil output, stop, return and other actions can be controlled at any time, so as to have the correct operation position in the work.
4.Equipped with visual hydraulic oil window, you can clearly see whether the hydraulic oil is within the normal range, which is helpful to protect the normal use of the hydraulic pump
5.Have function of pressure maintaining.
3.Model:PE2D Technical specification:
Oil capacity:5L
Flow:0.3L/min(high pressure),4L/min(low pressure)
Voltage:AC220V/0.37kW
Pressure:700bar
Weight:25kg
Characteristic:
1. 3-meter wired remote controller to control the actions of oil delivery and oil return
2. Equipped with a pressure gauge, you can clearly see the pressure required for crimping or cutting
3. Double-circuit manual control
4. It is equipped with a visual hydraulic oil window to clearly see whether the hydraulic oil within the normal range. It help to protect the normal use of the hydraulic pump
5. Adopt high and low pressure double-speed automatic switching design, which can easily promote the use of 60t, 100t, 200t and other single-acting or double-acting tools
Dimensions
| Model | PE1 | PE2 | PE2D |
| Oil Capacity (L) | 5 | 2.4 | 5 |
| Flow - High Pressure (L/min) | 0.7 | 0.32 | 0.3 |
| Flow - Low Pressure (L/min) | 6 | 2.6 | 4 |
| Voltage (V) | AC220 | AC220 | AC220 |
| Power (W / kW) | 750 W | 340 W | 0.37 / kW |
| Maximum Pressure (bar) | 700 | 700 | 700 |
| Weight (kg) | 25 | 16 | 25 |
| Length of Oil Hose (m) | 2 | 2 | N/A |
Video
FQAs
what is an electric hydraulic pump station?
an electric hydraulic pump station is a unit that uses an electric motor to power a hydraulic pump, which generates pressure to operate various hydraulic tools and equipment.
how does an electric hydraulic pump station work?
an electric hydraulic pump station works by converting electrical energy into mechanical energy through the use of an electric motor. the motor drives a hydraulic pump, which then creates hydraulic pressure that can be used to power hydraulic tools and equipment.
what are the advantages of an electric hydraulic pump station?
some of the advantages of an electric hydraulic pump station include greater energy efficiency, cleaner operation with less environmental impact, reduced maintenance requirements, and smoother and more precise performance.
what applications are electric hydraulic pump stations commonly used for?
electric hydraulic pump stations are commonly used in a wide range of applications, including construction, manufacturing, mining, agriculture, transportation, and material handling, among others.
what factors should be considered when selecting an electric hydraulic pump station?
when selecting an electric hydraulic pump station, important factors to consider include the required hydraulic pressure and flow rate, the available electrical power supply, the operating environment and conditions, and the specific application requirements.
