Plug-In Torque Wrench,9x12,14x18mm,DA-1 Series
-
Brand：SAIVS
Accuracy：±4%
Model Number：DA-1
Torque range(Nm)：1-500Nm
Specification: 9x12,14x18
L/W/H(mm)：208-653/28-45/28-42
Weight(kg)：0.4-1.89
Place of Origin: China
Customized: OEM,ODM
Minimum Order: 1Piece
Sample:Contact us for free samples
Description
The Torque Wrench body is made of
durable metal structure, with ±4% torque error.
The plastic handle is made of aluminum
alloy for oil resistance, anti-slip, and durability.
The alloy steel pipe has a permanent
torque scale for easy reading in metric and English systems.
It has interchangeable heads in sizes
of 9x12 and 14x18 concave square heads.
Each torque wrench has a unique product identification code.
Dimensions
| DA-1 Type Plug-in torque wrench | |||||||||
| Model Number | Torque range | Specifications | Fine Scale/N.m | Length/mm | Width/mm | Height/mm | Weight/Kg | ||
| N.m | Lbf.ft | N.m | Lbf.ft | ||||||
| DA02601 | 1-5 | 2-9 | 9x12 | 0.05 | 0.067 | 208 | 28 | 28 | 0.4 |
| DA02602 | 2-12 | 2-9 | 9x12 | 0.1 | 0.074 | 208 | 34 | 30 | 0.4 |
| DA02603 | 4-20 | 3-15 | 9x12 | 0.2 | 0.147 | 208 | 34 | 30 | 0.45 |
| DA02604 | 5-25 | 4-19 | 9x12 | 0.2 | 0.147 | 208 | 34 | 30 | 0.45 |
| DA02605 | 6-30 | 5-23 | 9x12 | 0.2 | 0.147 | 268 | 34 | 30 | 0.48 |
| DA02606 | 10-60 | 9-46 | 9x12 | 0.5 | 0.369 | 268 | 41 | 34 | 0.8 |
| DA02607 | 10-100 | 7-75 | 9x12 | 0.5 | 0.369 | 388 | 41 | 34 | 0.81 |
| DA02608 | 20-100 | 15-75 | 9x12 | 0.5 | 0.369 | 388 | 41 | 34 | 0.81 |
| DA02609 | 25-125 | 20-94 | 9x12 | 0.5 | 0.369 | 388 | 41 | 34 | 0.81 |
| DA02610 | 40-200 | 30-150 | 14x18 | 1.0 | 0.738 | 448 | 41 | 34 | 0.87 |
| DA02611 | 20-210 | 15-155 | 14x18 | 1.0 | 0.738 | 448 | 41 | 34 | 0.87 |
| DA02612 | 60-300 | 45-226 | 14x18 | 1.0 | 0.738 | 603 | 45 | 42 | 1.87 |
| DA02613 | 65-335 | 50-250 | 14x18 | 1.0 | 0.738 | 603 | 45 | 42 | 1.87 |
| DA02614 | 65-350 | 50-260 | 14x18 | 1.0 | 0.738 | 603 | 45 | 42 | 1.87 |
| DA02615 | 80-400 | 60-300 | 14x18 | 2.0 | 1.475 | 653 | 45 | 42 | 1.89 |
| DA02616 | 100-500 | 80-376 | 14x18 | 2.0 | 1.475 | 653 | 45 | 42 | 1.89 |
Video
FQAs
How is the accuracy and reliability of a Plug-In Torque Wrench ensured?
The accuracy and reliability of a Plug-In Torque Wrench are ensured through regular calibration,
where its readings are compared to a known standard to check for any deviations or errors.
Calibration helps maintain accurate torque measurements and ensures the wrench performs within acceptable limits.
How can one determine if a Plug-In Torque Wrench has reached the set torque value?
Plug-In Torque Wrenches typically indicate the achievement of a set torque
value through an audible click or sound,or visual indicators such as a dial or digital display.
These indicators alert the user when the desired torque has been reached, ensuring proper tightening.
Application
Installing pipeline components
Securing structural steel connections
Aircraft maintenance
Shipbuilding and marine applications
Composite materials fabrication
Wind tunnel testing
Building and testing prototype vehicles
