Plug-In Torque Wrench,9x12,14x18mm,DP-1 Series
-
Brand：SAIVS
Accuracy：±4%
Model Number：DP-1
Torque range(Nm)：1-500Nm
Specification: 9x12,14x18
L/W/H(mm)：208-653/28-45/28-38
Weight(kg)：0.4-1.89
Place of Origin: China
Customized: OEM,ODM
Minimum Order: 1Piece
Sample:Contact us for free samples
Description
The Torque Wrench body is made of metal structure,
sturdy and durable, with a long service life.
Accuracy: Torque error value ± 4%.
The wrench's plastic handle is made of imported materials,
providing oil resistance, anti-slip, anti-drop, and durability.
The permanent torque scale on the alloy steel pipe is easy for users to read,
with a comparison between metric and English systems.
Interchangeable head design, includes 9x12
and 14x18 concave square heads for torque wrench interface.
Each torque wrench has a unique product identification code.
Dimensions
| DP-1 Type Plug-in torque wrench | |||||||||
| Model Number | Torque range | Specification | Fine Scale/N.m | Length/mm | Width/mm | Height/mm | Weight/Kg | ||
| N.m | Lbf.ft | N.m | Lbf.ft | ||||||
| DP02501 | 1-5 | 2-9 | 9x12 | 0.05 | 0.067 | 208 | 28 | 28 | 0.4 |
| DP02502 | 2-12 | 2-9 | 9x12 | 0.1 | 0.074 | 208 | 34 | 30 | 0.4 |
| DP02503 | 4-20 | 3-15 | 9x12 | 0.2 | 0.147 | 208 | 34 | 30 | 0.45 |
| DP02504 | 5-25 | 4-19 | 9x12 | 0.2 | 0.147 | 208 | 34 | 30 | 0.45 |
| DP02505 | 6-30 | 5-23 | 9x12 | 0.2 | 0.147 | 268 | 34 | 30 | 0.48 |
| DP02506 | 10-60 | 9-46 | 9x12 | 0.5 | 0.369 | 268 | 41 | 34 | 0.8 |
| DP02507 | 10-100 | 7-75 | 9x12 | 0.5 | 0.369 | 388 | 41 | 34 | 0.81 |
| DP02508 | 20-100 | 15-75 | 9x12 | 0.5 | 0.369 | 388 | 41 | 34 | 0.81 |
| DP02509 | 25-125 | 20-94 | 9x12 | 0.5 | 0.369 | 388 | 41 | 34 | 0.81 |
| DP02510 | 40-200 | 30-150 | 14x18 | 1.0 | 0.738 | 448 | 41 | 34 | 0.87 |
| DP02511 | 20-210 | 15-155 | 14x18 | 1.0 | 0.738 | 448 | 41 | 34 | 0.87 |
| DP02512 | 60-300 | 45-226 | 14x18 | 1.0 | 0.738 | 603 | 45 | 38 | 1.87 |
| DP02513 | 65-335 | 50-250 | 14x18 | 1.0 | 0.738 | 603 | 45 | 38 | 1.87 |
| DP02514 | 65-350 | 50-260 | 14x18 | 1.0 | 0.738 | 603 | 45 | 38 | 1.87 |
| DP02515 | 80-400 | 60-300 | 14x18 | 2.0 | 1.475 | 653 | 45 | 38 | 1.89 |
| DP02516 | 100-500 | 80-376 | 14x18 | 2.0 | 1.475 | 653 | 45 | 38 | 1.89 |
Video
FQAs
How can one determine if a Plug-In Torque Wrench has reached the set torque value?
Plug-In Torque Wrenches typically indicate the achievement of a set torque
value through an audible click or sound,or visual indicators such as a dial or digital display.
These indicators alert the user when the desired torque has been reached, ensuring proper tightening.
What are some common problems and faults associated with Plug-In Torque Wrenches?
Common problems with Plug-In Torque Wrenches include incorrect torque settings,
damage or wear to the wrench's mechanism, loose or damaged components, and calibration drift over time.
To resolve these issues, verify torque settings, inspect and replace damaged components,
recalibrate as needed, and seek professional assistance if necessary.
Application
Working on lawnmower blades
Attaching roof trusses
Erecting wind turbines
Aerospace manufacturing
Electronics assembly
Robotics and automation
Research and development in various industries
