CLL Series Single-Acting High Tonnage Lock-Nut Hydraulic Cylinders
-
Capacity: 50-800ton
Stroke: 50-300mm
Max.pressure: 700ba/10000psi
weight:18-1306kg
Oil Capacity:392-37698(cm3)
Minimum Order:1Piece
Manufacturer:SAIVS
Country of Origin:China
Sample:Contact us for free samples
Description
Single acting, loads return.
Special painted surface to increase corrosion resistance.
Lock nut ensure the safety of long time load holding.
All model include quick couplings (NPT3/8"-18) and dust-proof cap.
Overflow port function could limit the stroke.
The exclusive guide Ring is designed absorbs eccentric loading without galling cylinder parts,reduces wear and extending life.
Removable hardened saddles protect plunger during lifting and pressing.
Double-acting mechanical lock nut cylinder could be Customized.
Lock nut ensure the safety of long time load holding.
Top and side mounted lifting eyes.
Overflow port function could limit the stroke.
SMA-NPT3/8 coupler and dustcap.When low height with high force is required, SSL Series hydraulic pancake cylinders with lock nut offer the solution to lift the fiest few centimetres. ALL CLLSeries cylinders include integral tilt saddles with maximum tilt angles up to 5°.
Select appropriate pumps for offer optimum combination.Select SAIVS high quality high pressure hoses.
Dimensions
| Cylinder Capacity | Stroke | Model Number | Cylinder Effective Area | Oil Capacity | Collapsed Height | Extended Height | Outside Dia. | Cylinder Bore Dia. | Plunger Dia. | Base to Advance Port | Saddle Protrusion from Plgr. | Plunger to Base | Plunger to Mounting Hole | Weight | Mounting Hole Dimensions | |||||
| Model Number | Bolt Circle | Hole Dia. | Counter Bore Dia. | Counter Bore Depth | ||||||||||||||||
| A | B | C1XC2 | D | E | F | J | M | N | O | P | U | V | ||||||||
| ton(KN) | (mm) | (cm2) | (cm3) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (kg) | (mm) | (mm) | (mm) | (mm) | |||
| 10(101) | 11 | SRSM-100 | 15.9 | 18 | 44 | 55 | 83X60 | 45 | 35 | 23 | 1 | 31.5 | 34 | 1.4 | SRSM-100 | 36.6 | 7.1 | 10.7 | 7.9 | |
| 20(201) | 12 | SRSM-200 | 31.1 | 37 | 52 | 64 | 102X80 | 63 | 50 | 23 | 1 | 41 | 39 | 2.2 | SRSM-200 | 49.3 | 10 | 15.1 | 9.9 | |
| 30(295) | 13 | SRSM-300 | 45.3 | 59 | 58 | 71 | 117X97 | 76 | 60 | 23 | 1 | 48.5 | 47 | 4.2 | SRSM-300 | 52.3 | 10 | 15.9 | 11.2 | |
| 50(549) | 16 | SRSM-500 | 78.5 | 125 | 67 | 83 | 150X125 | 100 | 80 | 23 | 1 | 63 | 60 | 7.4 | SRSM-500 | 66.5 | 11 | 19 | 12.7 | |
| 75(718) | 16 | SRSM-750 | 116.8 | 187 | 79 | 96 | 177X152 | 122 | 100 | 21 | 1 | 76.5 | 73 | 12.7 | SRSM-750 | 76.2 | 13.5 | 20.6 | 14.2 | |
| 100(887) | 16 | SRSM-1000 | 153.9 | 246 | 87 | 103 | 203X179 | 140 | 112 | 23 | 1 | 89.5 | 84 | 15.5 | SRSM-1000 | 76.2 | 13.5 | 20.6 | 14.2 | |
| 150(1386) | 16 | SRSM-1500 | 232.2 | 371 | 98 | 114 | 236X212 | 170 | 145 | 25 | 2 | 106 | 92 | 28.7 | SRSM-1500 | 117.3 | 13.5 | 20.6 | 14.2 | |
Video
FQAs
what is a single-acting high tonnage lock-nut hydraulic cylinder?
answer: a single-acting high tonnage lock-nut hydraulic cylinder is a type of hydraulic cylinder that uses high-pressure fluid to generate force in one direction and has a lock-nut feature to hold the piston in place when not in use.
what is the maximum tonnage capacity for these cylinders?
answer: the maximum tonnage capacity for single-acting high tonnage lock-nut hydraulic cylinders varies depending on the model and manufacturer, but they can range from 50 tons to over 1,000 tons.
how do i choose the right size cylinder for my application?
answer: to choose the right size cylinder for your application, you need to consider factors such as the weight or force of the load, the distance the cylinder needs to travel, and the speed at which it needs to move. you should consult with a hydraulic systems expert or the manufacturer for guidance.
what kind of hydraulic fluid should i use with these cylinders?
answer: the type of hydraulic fluid you should use with single-acting high tonnage lock-nut hydraulic cylinders depends on the manufacturer's specifications, but most commonly used fluids include mineral oil-based hydraulic oil, water glycol, and synthetic hydraulic fluids.
how do i maintain and service these cylinders?
answer: regular maintenance and service are essential to keep single-acting high tonnage lock-nut hydraulic cylinders in good working condition. this includes checking for leaks, ensuring proper alignment and connection, replacing worn-out seals and hydraulic fluid, lubricating moving parts, and inspecting for signs of wear and tear. you should follow the manufacturer's recommendations for maintenance intervals and procedures.
Application
Construction equipment often requires precise positioning for maintenance and repair tasks, and hydraulic cylinder jacks provide the necessary lifting capability.
Automotive mechanics use hydraulic cylinder jacks to raise cars and trucks for various repair and maintenance tasks.
Event organizers use hydraulic cylinder jacks to adjust the height of stages and platforms for performances and presentations.
Railways use hydraulic cylinder jacks to lift locomotives, allowing access for inspections and maintenance.
Hydraulic cylinder jacks provide the lifting power needed to assemble large structures such as steel frameworks and industrial buildings.
Hydraulic cylinder jacksaid in positioning molds and dies in manufacturing processes, ensuring accurate product production.
Elevator systems require periodic maintenance, and hydraulic cylinder jacks are employed to lift and secure elevator cars for inspection and service.
